modest dimensions
31’1”
LENGTH
11’
HEIGHT
96.8”
WIDTH
75.2”
Interior Height
185”
Wheelbase
27,980 lbs
GVWR
74.4”
Front Overhang
114”
Rear Overhang
190 ft³
Underfloor Luggage Volume
Excellent maneuverability
27'5"
turning radius
19.5”
Alcoa Wheels
34+1 Reclining Seats
Business Partner
for your Ambitious Goals
modest dimensions
31’1”
LENGTH
11’
HEIGHT
96.8”
WIDTH
75.2”
Interior Height
185”
Wheelbase
27,980 lbs
GVWR
74.4”
Front Overhang
114”
Rear Overhang
190 ft³
Underfloor Luggage Volume
Excellent maneuverability
27'5"
turning radius
19.5”
Alcoa Wheels
80 US gal
Fuel Tank Capacity
5 US gal
DEF Tank Capacity
TS30 is designed to minimize repair cost & to get you back on the road quicker, limiting coach down time. The tool-free concept enables technicians to access all main components within seconds, boosting productivity.
Daily pre-trip checklist items are next to each other located in the engine room to save time while the upgraded single ATS unit provides unmatched mechanical access.
On the exterior, the three-piece front & rear bumpers, swing out rear fenders and quick release headlight system keeps repair cost at a minimum.
Cummins B Series
6-Cylinder 6.7L Diesel (EPA 21)
Low Fuel Consumption
environment-conscious performance
The New TS30 offers high performance, economic fuel consumption, comfortable driving comparable to that of a car, whereas the Allison B300 transmission increasing fuel economy.
Allison B300 Transmission
high-power performance
TEMSA TS30 offers high power performance paired with a Cummins-Allison powertrain providing improved fuel economy, cost savings and seamless drivability.
STANDARD EQUIPMENTS
Front Axle
ZF RL 55 EC independent, 11,023 lbs
Rear Axle
Dana 10.24R with 4.3 dif. ratio, 20,943 lbs
Wheels
19.5” Alcoa Dura-Bright Wheels
Tires
265/70R 19.5 Continental
Steering System
Power Steering System with Tilt and Telescopic Steering Wheel
Suspension
Independent Front Air Suspension Air Bags and Shock Absorbers
Full Lifting and Front Kneeling
Mirror
Chrome Upright Mirror w Integrated Turn Signals
Touchscreen 2 DIN REI A/V System AM/FM/DVD/MP3/B
Driver cockpit is spacious for enhanced driving comfort.
TS30 is set to become your diligent assistant in your journeys, with the safety systems to provide the highest level of support. The Bendix® ESP® system, ESC, ABS, and ATC functions to experience a high level of stability and handling. Features such as the cruise control, low voltage warning, and circuit separator on battery help make the rides safer.
ISRI™ Air Ride 3-Point Safety Belt
Electric Two-Piece Overlapping Sun Visor, Manual Driver Side Sun Visor
Driver cockpit is spacious for enhanced driving comfort, the entrance steps are wider and lower for easy entry and the passenger compartment is brighter with standard LED lighting. This modern design is completed with a digital cluster, new style seats and spacious overhead parcel racks for the ultimate travel experience.
The entrance steps are wider and lower for easy entry and the passenger compartment is brighter with standard LED lighting.
Sit back and relax in reclining seats while enjoyingthe new infotainment multimedia system withup to six monitors. Feel the smooth ride qualitywith our advanced air suspension system withairbags & Koni shock absorbers that accompanyfront independent suspension to ensure anunforgettable travel experience.
Electrical System
12-24 Volt, Continental Multiplex System, Digital Cluster
Battery
2x12 V 180Ah
Alternator
Prestolite 2X120 Ah
Lights
LED Headlights, DRL and Fog Light, LED Exterior & Interior Lighting
Diagnostic
Real Time Diagnostics of Engine, Transmission, Multiplex, A/C System
Bendix® Wingman® Fusion™ is now being offered on the redesigned TS45 adding to the comprehensive list of driver assistance safety systems (ABS, ATC, RSC, ESC). The existing lane departure warning system, tire pressure monitoring system, 3-point safety belts, tempered-laminated side windows, and the high level of structural integrity round out the standard safety line-up.
Brakes
Bendix® ESP® System
All Wheel Disc Brakes
the Bendix® ESP® System for Temsa Coach Bus - the ultimate safety solution for your fleet! With advanced features such as stability control and traction assistance, you can trust that your passengers are always in good hands. Say goodbye to unpredictable road conditions and hello to a smoother, safer ride with the Bendix® ESP® System. Upgrade your fleet today!
Antilock Braking
System
ABS is a safety feature that helps to prevent the wheels of a vehicle from locking up during braking. This system is especially important for large vehicles like coach buses, as their weight and size can make them more difficult to stop quickly in emergency situations.
Another benefit of ABS in coach buses is that it can help to reduce wear and tear on the brakes. When a wheel locks up during braking, it can cause the brake pads to wear down more quickly and lead to increased maintenance costs. By preventing the wheels from locking up, ABS can help to extend the life of the brake system and reduce maintenance costs over time.
Automatic Traction
Control
ATC can be particularly useful when driving on wet or icy roads, or when going up or down steep inclines. The system can help to prevent the wheels from spinning out of control or slipping, which can cause the driver to lose control of the vehicle. By keeping the wheels in contact with the road, ATC can help to improve the overall safety and stability of the bus.
Another benefit of ATC in coach buses is that it can help to improve fuel efficiency and reduce wear and tear on the tires. When the wheels spin out of control or lose traction, it can cause unnecessary wear on the tires and increase fuel consumption. By keeping the wheels in contact with the road, ATC can help to reduce the amount of wear on the tires and improve the overall efficiency of the bus.
Electronic Stability Control
Electronic Stability Control (ESC) is a safety feature that helps to prevent a vehicle from losing control and skidding or sliding during emergency maneuvers or in hazardous road conditions. ESC uses sensors to monitor the movement of the vehicle and detect any loss of traction or instability. If the system detects that the vehicle is starting to lose control, it will automatically apply the brakes and adjust the engine power to help the driver regain control.
Also ESC can help to improve passenger comfort and reduce the risk of injuries. When a bus loses control and starts to skid or slide, it can cause passengers to be thrown around or injured. ESC can help to prevent such accidents and keep passengers safe and comfortable during their journey.
Engine Brakes
Cummins VGT Engine Brake
Seating
3-Point Safety Seat Belts for Driver & Passengers
Fire Suppression System
Firetrace Engine Room
Automatic Fire Suppression System
Warnings
Brake Pad Wearing Indicator,
Low Voltage, Engine Door Open
Cruise Control
Cruise Control System
Thinking about indispensable elements of long distance voyages, one would immediately mention nice views, a safe ride and comfort. TS30 provides a unique travel experience for your passengers, with the wide and comfortable seats, the refreshing interior design, powerful air conditioning system and the WC. TS30 is set to meet your expectations with its seating arrangements, leg-room, distinctive flooring patterns and color options.
media
(4) 15” REI Monitors
usb
USB Plugs for Driver and Passengers
HVAC
Mobile Climate Control A/CRoof Cooling, Roof & Convector Heating
Max Cooling Capacity 87,430 BTU,
Max Heating Capacity 55,000 BTU
Restroom
Recirculating,
16 Gallon Tank
Passenger Modules
Adjustable Air Vents,
Reading Lights,
SpeakerThis
New style seats and spacious overhead parcel racks
Luggage Space
Expanded by 35%
for comfortable rides
Windows
Rear Window and Tempered Laminated Side Windows
Flooring
Gerflor Anticwood
Seating
34+1 Reclining Seats with Leather Headrest, Piping, Side Boxing, Footrest, Magazine Nets, Rubber Cup Holders
Restroom
Recirculating, with 16 Gallon Tank
Passenger Side Shades
Leather & Fabric Seat Options
REI HDMI Media Kit
REI Cordless Microphone
REI 360 Camera System
Preheater
Destination Sign
Driver’s Partition
Allison B300R
